USB Power Sensor Products, RF & Microwave Measurement

LB5900 Sensors are Platform Independent (Linux etc). All sensors compatible with Win XP, 7, 8, 10 & 11; 32 & 64 bit

We cover the RF and Microwave Power Measurement market with three types of USB power sensors. Our True RMS Sensors provide accurate, fast True RMS measurements. LadyBug Peak & Pulse sensors accurately make statistical measurements such as Peak and Pulse Power, Duty Cycle and Crest Factor. In addition to these measurements, our Pulse Profiling sensors offer triggered pulse measurements and statistical functions including CDF, CCDF and PDF measurements along with time domain trace visibility.

For quick, accurate average power measurement of any signal, consider one of our True RMS Sensors, these products are some of the best sensors on the market today and can deliver 2,000 measurements per second. And remember, our patented NoZero NoCal technology means that you do not need to zero the sensors before use, simply connect and measure, even for high accuracy at very low power levels.

All of our sensors feature USB 2.0, and optional external trigger in & out plus recorder out, all without external components. Our patented NoZero NoCal technology make these sensors ideal for test systems and other embedded applications. No need to switch the signal out to zero or calibrate the sensor, or to wait for internal circuitry, just measure. This can save thousands of dollars in switches, sources, and other components. We provide detailed specifications with a variety of example measurements from our sensors in the Using Ladybug Sensors section. Click the links below for more information.

True RMS Sensors 4 kHz to 67 GHz

HIGH ACCURACY ON ANY SIGNAL WITH ANY MODULATION

LadyBug True RMS Average Power Sensors deliver reliable, accurate power measurements for CW, Pulse, and modulated signals. These diode based sensors feature a wide dynamic range and a great VSWR. The optional external triggering input feature can be used without any external components. Recorder and Trigger outputs are also available. Our patented NoZero NoCal technology make these sensors ideal for calibration systems, automated test stations and other embedded applications.

LadyBug LB5900 Series True RMS Sensor Ordering Guide

Peak, Pulse and Average Sensors 10 MHz to 20 GHz

STATISTICAL PULSE & FAST AVERAGE MEASUREMENTS

These sensors provide quick and easy measurements of pulse power, continuous wave power and other signals. Many of our competitors claim to measure pulse power, however you must input your duty cycle and the power is calculated based on that. Our sensors offer trigger based measurements and the pulse itself is examined giving better measurement uncertainty. There is no need to input the duty cycle to calculate pulse measurements, our sensors measure it.

Wideband Pulse Profiling Sensors 50 MHz to 20 GHz

VISUAL TIME DOMAIN PULSE PROFILE, PULSE & FAST AVERAGE MEASUREMENTS

LadyBug wideband Power Sensors feed power waveform samples into high speed A/D converters. The measured power is processed and then delivered as required by the user. These sensors are capable of delivering everything from basic power, to time domain scope-like profiles of the modulated waveform, such as the pulse shown at right. Multiple time gated measurements, crest factor, pulse power, and statistical measurements are all possible with these sensors.

True RMS Sensors 4 kHz to 67 GHz
Peak, Pulse and Average Sensors
Pulse Profiling Sensors
LAN Compatible Sensors
Small Form Factor
All Sensors

LadyBug True RMS Power Sensors - USB Platform Independent

Our True RMS Sensors make fast accurate CW power measurements. These Sensors are available in frequency ranges that cover 4 kHz to 67 GHz. Select one of our new LB59XX True RMS Sensors with broad single sensor frequency coverage and excellent frequency flatness in the industry or add one of our LB5XXA high performance sensors to your system.

All of our sensors feature USB 2.0, and optional external trigger in & out plus recorder out, with no external components. Our patented NoZero NoCal technology makes these sensors ideal for test systems and other embedded applications. Our new platform independent sensors feature USBTMC and USBHID interfaces along with an optional SPI/I2C interface that adds to the long list of innovative features. We provide detailed specifications with a variety example measurements from our sensors in the Using Ladybug Sensors section. Click the links below for more information.

Sensor Link	Software Application	Sensors Frequency Range	Std Connector	Linux / SPI/I2C / Windows	U2000 Compatible	Available Options	Availability/Lead time
LB5908A	PMA-12	1 MHz to 8 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5908L	PMA-12	9 kHz to 8 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	8 Weeks
LB5912A	PMA-12	1 MHz to 12.5 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5918A	PMA-12	1 MHz to 18 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5918L	PMA-12	9 kHz to 18 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	8 Weeks
LB5926A	PMA-12	1 MHz to 26.5 GHz	3.5mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5926A-LAN	PMA-12	1 MHz to 26.5 GHz	3.5mm Male	All - Platform independent	Yes	001, 003, CW3, C03, MIL	Normally in Stock
LB5926L	PMA-12	9 kHz to 26.5 GHz	3.5mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	8 Weeks
LB5940A	PMA-12	1 MHz to 40 GHz	2.92mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5940L	PMA-12	9 kHz to 40 GHz	2.92mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	8 Weeks
LB5944A	PMA-12	1 MHz to 44 GHz	2.4mm Male	All - Platform independent	Yes	001, 003, 050, CW3, C03, SPI, UOP, MIL, SEC	8 Weeks
LB5944L	PMA-12	9 kHz to 44 GHz	2.4mm Male	All - Platform independent	Yes	001, 003, 050, CW3, C03, SPI, UOP, MIL, SEC	8 Weeks
LB5954L	PMA-12	9 kHz to 54 GHz	2.4mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL, SEC	6 Weeks
LB559A	PMA-3	10 MHz to 12.5 GHz	Specify	Win XP, to Win 11; 32 & 64 Bit	No	001, 003, CW3, C03	Stock with Type-N Male & SMA Female
LB5967L	PMA-12	9 kHz to 67 GHz	1.8mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL, SEC	8 Weeks
LB5975W	PMA-12	50 GHz to 75 GHz	WR-15	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL, SEC	12 Weeks
LB579A	PMA-3	10 MHz to 18 GHz	Specify	Win XP, to Win 11; 32 & 64 Bit	No	001, 003, CW3, C03	Stock with Type-N Male & SMA Female
LB589A	PMA-3	10 MHz to 26.5 GHz	Specify	Win XP, to Win 11; 32 & 64 Bit	No	001, 003, CW3, C03	Stock with SMA-Male
LBSF09L	PMA-12	4 KHz to 9 GHz	SMA Male	All Win versions, Linux., VISA	No	001, SPI, C03, ONM, OSM, ONF, 35M	Stock with SMA-Male
LBSF09A	PMA-12	1 MHz to 9 GHz	SMA Male	All Win versions, Linux., VISA	No	001, SPI, C03, ONM, OSM, ONF, 35M	Stock with SMA-Male

Contact us for the lead times on sensors with alternate connectors.

LadyBug USB Peak and Pulse Sensors

LadyBug Peak and pulse sensors, are very useful in many pulse applications. For repetitive pulses, these sensors provide certain statistical numerical pulse information. Today, most microwave communication and radar signals are pulsed. Fast statistical measurements can be invaluablee. To make the measurement, the sensor collects power levels and places them into buckets; enough time for several pulses to occur must be allowed. These buckets are then statistically processed. The Peak power is located and reported. The pulses proximal, mesial, distal and top line levels are located. Using this information, and per ANSI/IEEE Std 181-1977, these sensors automatically calculate and report accurate pulse power, duty cycle and crest factor to the user, as shown in the image above. We provide detailed specifications with a variety example measurements from our sensors in the Using Ladybug Sensors section. Click the links below for more information.

Sensor Link	Sensor's Software	Frequency Range	Measurement Type	Recommended usage	Type of signal/modulation	Interface
LB478A	PMA-3	10MHz to 8GHz	Peak, Pulse and Average power measurements	General use, ATE sytems, Manufacturing test, Lab & field, Radar and other pulse measurements within the sensors video bandwidth	CW and modulated signals	USB-Win XP, 7 & 8; 32 & 64 Bit
LB479A	PMA-3	10MHz to 8GHz	Peak, Pulse and Average power measurements, 80dB dynamic range	General use, ATE sytems, Manufacturing test, Lab & field, Radar and other pulse measurements within the sensors video bandwidth	CW and modulated signals	USB-Win XP, 7 & 8; 32 & 64 Bit

LadyBug USB Pulse Profiling Sensors

In addition to statistical information, pulse profiling sensors provide time domain trace measurements. The sensor measures RF power, converts and sends data points fast enough to build a time domain trace. The measurement can be triggered and the signals detail can be plotted for on-screen viewing as shown above. This was was made with a LadyBug LB480A sensor. Additionally, these sensors can make triggered pulse measurements such as pulse width and pulse repetition time along with all of the measurements made by our peak and pulse sensors. LadyBug’s Pulse Profiling Sensors also provides a full complement of statistical information such as CDF, CCDF and PDF.

We provide detailed specifications with a variety example measurements from our sensors in the Using Ladybug Sensors section. Click the links below for more information.

Sensor Link	Sensor's Software	Frequency Range	Measurement Type	Recommended usage	Type of signal/modulation	Interface
LB480A	PMA-3 PPA-4	50MHz to 8GHz	Time Domain Pulse Profile, Peak, Pulse and Average power measurements	General use, ATE sytems, Manufacturing test, Lab & field, Radar and other pulse measurements within the sensors video bandwidth	CW and modulated signals	USB - Win XP, 7 & 8; 32 & 64 Bit
LB680A	PMA-3 PPA-4	50MHz to 20GHz	Time Domain Pulse Profile, Peak, Pulse and Average power measurements	General use, ATE sytems, Manufacturing test, Lab & field, Radar and other pulse measurements within the sensors video bandwidth	CW and modulated signals	USB - Win XP, 7 & 8; 32 & 64 Bit

Sensor Link	Software Application	Sensors Frequency Range	Std Connector	Linux / SPI/I2C / Windows	U2000 Compatible	Available Options	Availability/Lead time
LB5908A	PMA-12	1 MHz to 8 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5908L	PMA-12	9 kHz to 8 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	8 Weeks
LB5912A	PMA-12	1 MHz to 12.5 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5918A	PMA-12	1 MHz to 18 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5918L	PMA-12	9 kHz to 18 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	8 Weeks
LB5926A	PMA-12	1 MHz to 26.5 GHz	3.5mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5926A-LAN	PMA-12	1 MHz to 26.5 GHz	3.5mm Male	All - Platform independent	Yes	001, 003, CW3, C03, MIL	Normally in Stock
LB5926L	PMA-12	9 kHz to 26.5 GHz	3.5mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	8 Weeks
LB5940A	PMA-12	1 MHz to 40 GHz	2.92mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5940L	PMA-12	9 kHz to 40 GHz	2.92mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	8 Weeks
LB5944A	PMA-12	1 MHz to 44 GHz	2.4mm Male	All - Platform independent	Yes	001, 003, 050, CW3, C03, SPI, UOP, MIL, SEC	8 Weeks
LB5944L	PMA-12	9 kHz to 44 GHz	2.4mm Male	All - Platform independent	Yes	001, 003, 050, CW3, C03, SPI, UOP, MIL, SEC	8 Weeks
LB5954L	PMA-12	9 kHz to 54 GHz	2.4mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL, SEC	6 Weeks
LB5967L	PMA-12	9 kHz to 67 GHz	1.8mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL, SEC	8 Weeks
LB5975W	PMA-12	50 GHz to 75 GHz	WR-15	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL, SEC	12 Weeks

Sensor Link	Software Application	Sensors Frequency Range	Std Connector	Linux / SPI/I2C / Windows	U2000 Compatible	Available Options	Availability/Lead time
LBSF09L	PMA-12	4 KHz to 9 GHz	SMA Male	Win XP, 7, 8, 10; 32 & 64 Bit	No	001, SPI, C03, ONM, OSM, ONF, 35M	Stock with SMA-Male
LBSF09A	PMA-12	1 MHz to 9 GHz	SMA Male	Win XP, 7, 8, 10; 32 & 64 Bit	No	001, SPI, C03, ONM, OSM, ONF, 35M	Stock with SMA-Male

Sensor Link	Sensor's Software	Frequency Range	Measurement Type	Recommended usage	Type of signal/modulation	Linux / SPI/I2C / Windows
LB5908A	PMA-12	1MHz to 8GHz	High acuracy average power measurements	General purpose, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5908L	PMA-12	9kHz to 8GHz	High acuracy average power measurements	EMC work, Source Calibration, General use, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5912A	PMA-12	1MHz to 12.5GHz	High acuracy average power measurements	General purpose, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5918A	PMA-12	1MHz to 18GHz	High acuracy average power measurements	General purpose, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5918L	PMA-12	9kHz to 18GHz	High acuracy average power measurements	EMC work, Source Calibration, General use, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5926A	PMA-12	1MHz to 26.5GHz	High acuracy average power measurements	General purpose, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5926A-LAN	PMA-12	1MHz to 26.5GHz	High acuracy average power measurements	General purpose, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5926L	PMA-12	9kHz to 26.5GHz	High acuracy average power measurements	EMC work, Source Calibration, General use, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5940A	PMA-12	1MHz to 40GHz	High acuracy average power measurements	General purpose, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5940L	PMA-12	9kHz to 40GHz	High acuracy average power measurements	EMC work, Source Calibration, General use, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5944A	PMA-12	1MHz to 44GHz	High acuracy average power measurements	EMC work, Source Calibration, General use, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5944L	PMA-12	9kHz to 44GHz	High acuracy average power measurements	EMC work, Source Calibration, General use, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5954L	PMA-12	9kHz to 54GHz	High acuracy average power measurements	EMC work, Source Calibration, General use, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB559A	PMA-3	10MHz to 12.5GHz	High acuracy average power measurements	General, ATE sytems, Calibration applications, Manufacturing test, Lab & field	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	Win XP, 7 & 8, 10; 32 & 64 Bit
LB5967L	PMA-12	9kHz to 67GHz	High acuracy average power measurements	EMC work, Source Calibration, General use, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5975W	PMA-12	50GHz to 75GHz	High acuracy average power measurements	EMC work, Source Calibration, General use, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB579A	PMA-3	10MHz to 18GHz	High acuracy average power measurements	General, ATE sytems, Calibration applications, Manufacturing test, Lab & field	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	Win XP, 7, 8, 10; 32 & 64 Bit
LB589A	PMA-3	10MHz to 26.5GHz	High acuracy average power measurements	General, ATE sytems, Calibration applications, Manufacturing test, Lab & field	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	Win XP, 7, 8, 10; 32 & 64 Bit
LBSF09	PMA-12	4 KHz to 9 GHz	High acuracy average power measurements	Useful in research & development, manufacturing & service applications including radar, satellite, and telecommunications	Any including 802.11ac, gsm, CDMA 2000, CDMA (IS-95), TDMA, Multi-Tone, OFDM, CW, QAM	Win XP, 7, 8, 10; 32 & 64 Bit
LB478A	PMA-3	10MHz to 8GHz	Peak, Pulse and Average power measurements	General use, ATE sytems, Manufacturing test, Lab & field, Radar and other pulse measurements within the sensors video bandwidth	CW and modulated signals	Win XP, 7, 8, 10; 32 & 64 Bit
LB479A	PMA-3	10MHz to 8GHz	Peak, Pulse and Average power measurements, 80dB dynamic range	General use, ATE sytems, Manufacturing test, Lab & field, Radar and other pulse measurements within the sensors video bandwidth	CW and modulated signals	Win XP, 7 & 8; 32 & 64 Bit
LB480A	PMA-3 PPA-4	50MHz to 8GHz	Time Domain Pulse Profile, Peak, Pulse and Average power measurements	General use, ATE sytems, Manufacturing test, Lab & field, Radar and other pulse measurements within the sensors video bandwidth	CW and modulated signals	Win XP, 7 & 8; 32 & 64 Bit
LB680A	PMA-3 PPA-4	50MHz to 20GHz	Time Domain Pulse Profile, Peak, Pulse and Average power measurements	General use, ATE sytems, Manufacturing test, Lab & field, Radar and other pulse measurements within the sensors video bandwidth	CW and modulated signals	Win XP, 7 & 8; 32 & 64 Bit

True RMS Sensors 4 kHz to 67 GHz

LadyBug True RMS Power Sensors - USB Platform Independent

Sensor Link	Software Application	Sensors Frequency Range	Std Connector	Linux / SPI/I2C / Windows	U2000 Compatible	Available Options	Availability/Lead time
LB5908A	PMA-12	1 MHz to 8 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5908L	PMA-12	9 kHz to 8 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	8 Weeks
LB5912A	PMA-12	1 MHz to 12.5 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5918A	PMA-12	1 MHz to 18 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5918L	PMA-12	9 kHz to 18 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	8 Weeks
LB5926A	PMA-12	1 MHz to 26.5 GHz	3.5mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5926A-LAN	PMA-12	1 MHz to 26.5 GHz	3.5mm Male	All - Platform independent	Yes	001, 003, CW3, C03, MIL	Normally in Stock
LB5926L	PMA-12	9 kHz to 26.5 GHz	3.5mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	8 Weeks
LB5940A	PMA-12	1 MHz to 40 GHz	2.92mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5940L	PMA-12	9 kHz to 40 GHz	2.92mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	8 Weeks
LB5944A	PMA-12	1 MHz to 44 GHz	2.4mm Male	All - Platform independent	Yes	001, 003, 050, CW3, C03, SPI, UOP, MIL, SEC	8 Weeks
LB5944L	PMA-12	9 kHz to 44 GHz	2.4mm Male	All - Platform independent	Yes	001, 003, 050, CW3, C03, SPI, UOP, MIL, SEC	8 Weeks
LB5954L	PMA-12	9 kHz to 54 GHz	2.4mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL, SEC	6 Weeks
LB559A	PMA-3	10 MHz to 12.5 GHz	Specify	Win XP, to Win 11; 32 & 64 Bit	No	001, 003, CW3, C03	Stock with Type-N Male & SMA Female
LB5967L	PMA-12	9 kHz to 67 GHz	1.8mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL, SEC	8 Weeks
LB5975W	PMA-12	50 GHz to 75 GHz	WR-15	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL, SEC	12 Weeks
LB579A	PMA-3	10 MHz to 18 GHz	Specify	Win XP, to Win 11; 32 & 64 Bit	No	001, 003, CW3, C03	Stock with Type-N Male & SMA Female
LB589A	PMA-3	10 MHz to 26.5 GHz	Specify	Win XP, to Win 11; 32 & 64 Bit	No	001, 003, CW3, C03	Stock with SMA-Male
LBSF09L	PMA-12	4 KHz to 9 GHz	SMA Male	All Win versions, Linux., VISA	No	001, SPI, C03, ONM, OSM, ONF, 35M	Stock with SMA-Male
LBSF09A	PMA-12	1 MHz to 9 GHz	SMA Male	All Win versions, Linux., VISA	No	001, SPI, C03, ONM, OSM, ONF, 35M	Stock with SMA-Male

Contact us for the lead times on sensors with alternate connectors.

Peak, Pulse and Average Sensors

LadyBug USB Peak and Pulse Sensors

Sensor Link	Sensor's Software	Frequency Range	Measurement Type	Recommended usage	Type of signal/modulation	Interface
LB478A	PMA-3	10MHz to 8GHz	Peak, Pulse and Average power measurements	General use, ATE sytems, Manufacturing test, Lab & field, Radar and other pulse measurements within the sensors video bandwidth	CW and modulated signals	USB-Win XP, 7 & 8; 32 & 64 Bit
LB479A	PMA-3	10MHz to 8GHz	Peak, Pulse and Average power measurements, 80dB dynamic range	General use, ATE sytems, Manufacturing test, Lab & field, Radar and other pulse measurements within the sensors video bandwidth	CW and modulated signals	USB-Win XP, 7 & 8; 32 & 64 Bit

Pulse Profiling Sensors

LadyBug USB Pulse Profiling Sensors

We provide detailed specifications with a variety example measurements from our sensors in the Using Ladybug Sensors section. Click the links below for more information.

Sensor Link	Sensor's Software	Frequency Range	Measurement Type	Recommended usage	Type of signal/modulation	Interface
LB480A	PMA-3 PPA-4	50MHz to 8GHz	Time Domain Pulse Profile, Peak, Pulse and Average power measurements	General use, ATE sytems, Manufacturing test, Lab & field, Radar and other pulse measurements within the sensors video bandwidth	CW and modulated signals	USB - Win XP, 7 & 8; 32 & 64 Bit
LB680A	PMA-3 PPA-4	50MHz to 20GHz	Time Domain Pulse Profile, Peak, Pulse and Average power measurements	General use, ATE sytems, Manufacturing test, Lab & field, Radar and other pulse measurements within the sensors video bandwidth	CW and modulated signals	USB - Win XP, 7 & 8; 32 & 64 Bit

LAN Compatible Sensors

Sensor Link	Software Application	Sensors Frequency Range	Std Connector	Linux / SPI/I2C / Windows	U2000 Compatible	Available Options	Availability/Lead time
LB5908A	PMA-12	1 MHz to 8 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5908L	PMA-12	9 kHz to 8 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	8 Weeks
LB5912A	PMA-12	1 MHz to 12.5 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5918A	PMA-12	1 MHz to 18 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5918L	PMA-12	9 kHz to 18 GHz	Type-N Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	8 Weeks
LB5926A	PMA-12	1 MHz to 26.5 GHz	3.5mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5926A-LAN	PMA-12	1 MHz to 26.5 GHz	3.5mm Male	All - Platform independent	Yes	001, 003, CW3, C03, MIL	Normally in Stock
LB5926L	PMA-12	9 kHz to 26.5 GHz	3.5mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	8 Weeks
LB5940A	PMA-12	1 MHz to 40 GHz	2.92mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	Normally in Stock
LB5940L	PMA-12	9 kHz to 40 GHz	2.92mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL	8 Weeks
LB5944A	PMA-12	1 MHz to 44 GHz	2.4mm Male	All - Platform independent	Yes	001, 003, 050, CW3, C03, SPI, UOP, MIL, SEC	8 Weeks
LB5944L	PMA-12	9 kHz to 44 GHz	2.4mm Male	All - Platform independent	Yes	001, 003, 050, CW3, C03, SPI, UOP, MIL, SEC	8 Weeks
LB5954L	PMA-12	9 kHz to 54 GHz	2.4mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL, SEC	6 Weeks
LB5967L	PMA-12	9 kHz to 67 GHz	1.8mm Male	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL, SEC	8 Weeks
LB5975W	PMA-12	50 GHz to 75 GHz	WR-15	All - Platform independent	Yes	001, 003, CW3, C03, SPI, UOP, MIL, SEC	12 Weeks

Small Form Factor

Sensor Link	Software Application	Sensors Frequency Range	Std Connector	Linux / SPI/I2C / Windows	U2000 Compatible	Available Options	Availability/Lead time
LBSF09L	PMA-12	4 KHz to 9 GHz	SMA Male	Win XP, 7, 8, 10; 32 & 64 Bit	No	001, SPI, C03, ONM, OSM, ONF, 35M	Stock with SMA-Male
LBSF09A	PMA-12	1 MHz to 9 GHz	SMA Male	Win XP, 7, 8, 10; 32 & 64 Bit	No	001, SPI, C03, ONM, OSM, ONF, 35M	Stock with SMA-Male

All Sensors

Sensor Link	Sensor's Software	Frequency Range	Measurement Type	Recommended usage	Type of signal/modulation	Linux / SPI/I2C / Windows
LB5908A	PMA-12	1MHz to 8GHz	High acuracy average power measurements	General purpose, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5908L	PMA-12	9kHz to 8GHz	High acuracy average power measurements	EMC work, Source Calibration, General use, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5912A	PMA-12	1MHz to 12.5GHz	High acuracy average power measurements	General purpose, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5918A	PMA-12	1MHz to 18GHz	High acuracy average power measurements	General purpose, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5918L	PMA-12	9kHz to 18GHz	High acuracy average power measurements	EMC work, Source Calibration, General use, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5926A	PMA-12	1MHz to 26.5GHz	High acuracy average power measurements	General purpose, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5926A-LAN	PMA-12	1MHz to 26.5GHz	High acuracy average power measurements	General purpose, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5926L	PMA-12	9kHz to 26.5GHz	High acuracy average power measurements	EMC work, Source Calibration, General use, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5940A	PMA-12	1MHz to 40GHz	High acuracy average power measurements	General purpose, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5940L	PMA-12	9kHz to 40GHz	High acuracy average power measurements	EMC work, Source Calibration, General use, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5944A	PMA-12	1MHz to 44GHz	High acuracy average power measurements	EMC work, Source Calibration, General use, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5944L	PMA-12	9kHz to 44GHz	High acuracy average power measurements	EMC work, Source Calibration, General use, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5954L	PMA-12	9kHz to 54GHz	High acuracy average power measurements	EMC work, Source Calibration, General use, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB559A	PMA-3	10MHz to 12.5GHz	High acuracy average power measurements	General, ATE sytems, Calibration applications, Manufacturing test, Lab & field	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	Win XP, 7 & 8, 10; 32 & 64 Bit
LB5967L	PMA-12	9kHz to 67GHz	High acuracy average power measurements	EMC work, Source Calibration, General use, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB5975W	PMA-12	50GHz to 75GHz	High acuracy average power measurements	EMC work, Source Calibration, General use, ATE sytems, Calibration applications, Manufacturing test, Lab & field, Unattended applications	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	All - Platform independent
LB579A	PMA-3	10MHz to 18GHz	High acuracy average power measurements	General, ATE sytems, Calibration applications, Manufacturing test, Lab & field	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	Win XP, 7, 8, 10; 32 & 64 Bit
LB589A	PMA-3	10MHz to 26.5GHz	High acuracy average power measurements	General, ATE sytems, Calibration applications, Manufacturing test, Lab & field	Any including 802.11ac, gsm, cdma 2000, CDMA (IS-95), TDMA, Multi-Tome, OFDM, CW, QAM	Win XP, 7, 8, 10; 32 & 64 Bit
LBSF09	PMA-12	4 KHz to 9 GHz	High acuracy average power measurements	Useful in research & development, manufacturing & service applications including radar, satellite, and telecommunications	Any including 802.11ac, gsm, CDMA 2000, CDMA (IS-95), TDMA, Multi-Tone, OFDM, CW, QAM	Win XP, 7, 8, 10; 32 & 64 Bit
LB478A	PMA-3	10MHz to 8GHz	Peak, Pulse and Average power measurements	General use, ATE sytems, Manufacturing test, Lab & field, Radar and other pulse measurements within the sensors video bandwidth	CW and modulated signals	Win XP, 7, 8, 10; 32 & 64 Bit
LB479A	PMA-3	10MHz to 8GHz	Peak, Pulse and Average power measurements, 80dB dynamic range	General use, ATE sytems, Manufacturing test, Lab & field, Radar and other pulse measurements within the sensors video bandwidth	CW and modulated signals	Win XP, 7 & 8; 32 & 64 Bit
LB480A	PMA-3 PPA-4	50MHz to 8GHz	Time Domain Pulse Profile, Peak, Pulse and Average power measurements	General use, ATE sytems, Manufacturing test, Lab & field, Radar and other pulse measurements within the sensors video bandwidth	CW and modulated signals	Win XP, 7 & 8; 32 & 64 Bit
LB680A	PMA-3 PPA-4	50MHz to 20GHz	Time Domain Pulse Profile, Peak, Pulse and Average power measurements	General use, ATE sytems, Manufacturing test, Lab & field, Radar and other pulse measurements within the sensors video bandwidth	CW and modulated signals	Win XP, 7 & 8; 32 & 64 Bit

Selecting a Power Sensor

LB5900 Sensors are Platform Independent (Linux etc). All sensors compatible with Win XP, 7, 8, 10 & 11; 32 & 64 bit

True RMS Sensors 4 kHz to 67 GHz

Peak, Pulse and Average Sensors 10 MHz to 20 GHz

Wideband Pulse Profiling Sensors 50 MHz to 20 GHz

LadyBug True RMS Power Sensors - USB Platform Independent

Contact us for the lead times on sensors with alternate connectors.

LadyBug USB Peak and Pulse Sensors

LadyBug USB Pulse Profiling Sensors

LadyBug True RMS Power Sensors - USB Platform Independent

Contact us for the lead times on sensors with alternate connectors.

LadyBug USB Peak and Pulse Sensors

LadyBug USB Pulse Profiling Sensors
